Carter Carburetor #1bbl BBS - Kit and Parts

#G8 - WASHER

#62-59 - ROD RETAINER

#101-539 - CHOKE PULL-OFF

#82-4 - LOCK WASHER ( 3/16″ )

#66-10 - CHOKE PULL-OFF BACK SPRING

#83-4 - LEAD BALL ( 1/4″ )

#G640 - BOWL COVER GASKET

#0-90 - RIVET PLUG ( Aluminum )

#31-509 - VITON NEEDLE & SEAT ASSEMBLY ( .101 Orifice ) ( 5/16″ Inverted Flare )

#16-91 - IDLE ADJUSTING SCREW ( 10-32X1.502 )

#G460 - STEP UP PISTON GASKET ( Rubber )

#32-11 - ( 3/64″X3/8″ ) COTTER PIN

#90-46 - FUEL INLET FITTING

#80-42 - WIRE CLAMP SCREW ( 8-32X5/16″ )

#22-54 - IDLE VENT VALVE ( TOP )

#62-61 - ROD CLIP RETAINER

#G850 - FLANGE GASKET

#G652 - RUBBER CAP ( 5/32″ )

#17-40 - BOWL VENT TUBE ( OD .375″X1.365″ ) Length

#90-12 - CHECK BALL ( 5/32″ Steel )

#G472 - THROTTLE BODY GASKET

#0-86 - RIVET PLUG ( Aluminum )

#31-504 - VITON NEEDLE & SEAT ASSEMBLY ( .086 Orifice ) ( 1/8″ M.P.T. )

#16-39 - IDLE ADJUSTING SCREW ( 10-32X1.391 )

#G75 - PUMP JET GASKET ( Fiber )

#62-104 - ROD RETAINER

#64-250 - LEATHER PUMP ASSEMBLY

#75-47 - STEP UP PISTON PLATE SCREW 6-32 ( Theads )

#66-51 - IDLE ADJUSTING SCREW SPRING

#62-62 - ROD RETAINER

#G483 - FLANGE GASKET

#85-48 - EXPANSION PLUG ( 5/8″ Aluminum )

#17-7-2 - PUMP DISCHARGE TUBE HOLDER ( OD .250″X1.000″ ) Length

#243F - CHOKE COVER GASKET

#22-53 - PUMP SPRING GUIDE

#31-503 - VITON NEEDLE & SEAT ASSEMBLY ( .086 Orifice ) ( 1/8″ F.P.T. )

#16-121 - IDLE ADJUSTING SCREW ( 1/4-36X1.195 )

#G365 - STEP UP JET GASKET ( Fiber )

#62-55 - ROD RETAINER

#66-32 - CHOKE THERMOSTAT SPRING

#75-27 - FAST IDLE CAM SCREW ( 1/4-28 )

#66-3 - IDLE ADJUSTING SCREW SPRING

#62-57 - E-CLIP RETAINER

#G698 - BOWL COVER GASKET

#0-70 - PUMP JET RIVET PLUG ( Aluminum )

#17-50 - VENT TUBE ( OD .187″X1.000″ ) Length

#G1115 - CHOKE COVER GASKET

#67-103 - INTAKE CHECK BALL RETAINER

#13F - NEEDLE & SEAT GASKET ( Fiber )

#80-43 - CHOKE PULL-OFF SCREW ( 8-32X3/8″ )

#G74 - WASHER ( Fiber )

#67-110 - BOWL VENT CLIP

#85-289 - FLOAT PIN RETAINER

#85-153 - IDLE LIMITER CAP

#17-131 - VACUUM TUBE ( OD .382″X1.718″ ) Length

#90-13 - CHECK BALL ( 3/16″ Steel )

#G699 - THROTTLE BODY GASKET

#0-50 - HIGHSPEED PASSAGE PLUG ( Aluminum )

#G1630 - NEEDLE & SEAT GASKET ( Fiber )

#16-124 - IDLE MIXTURE SCREW ( 10-32X1.442 )

#G604 - IDLE COMPENSATOR GASKET ( Cork )

#62-46 - ROD RETAINER

#90-56 - SPARK HOLE FITTING

#80-2 - THROTTLE PLATE SCREW ( 3-48X1/4″ )

#66-9 - IDLE SCREW SPRING

#62-60 - ROD CLIP RETAINER

#G748 - FLANGE GASKET

#G600-5 - RUBBER CAP ( 1/8″ )

#17-139 - VACUUM TUBE ( OD .190″X.986″ ) Length

#868F - AIR CLEANER MOUNTING GASKET

#0-106 - RIVET PLUG ( Aluminum )

#18-203 - NEEDLE

#16-9-1 - IDLE MIXTURE SCREW ( 10-32X1.075 )

#G272 - O-RING ( Buna )

#62-56 - ROD RETAINER

#64-169 - LEATHER PUMP ASSEMBLY

#75-18 - CAM SCREW ( 12-28 ) (Threads)

#66-1 - IDLE ADJUSTING SCREW SPRING

#62-42 - E-CLIP RETAINER

#G734 - BOWL COVER GASKET

#0-80 - PASSAGE PUMP JET PLUG ( Aluminum )

#17-49 - VENT TUBE ( OD .187″X1.250″ ) Length

#G97-1 - CHOKE COVER GASKET

#85-136 - PUMP SPRING RETAINER

#18-204 - NEEDLE

#80-83 - BOWL COVER SCREW ( 10-32X5/8″ )
